How to use your deviheat

™

heating system

The function of the button

The button can be turned both ways, is indicated by

or the button can be pressed/held, is indicated by

Symbol for frost

protection

Symbol for Timer On

Numerical display

for time, tempera-

ture, text, etc.

Flashing point for

actual time

Weekdays

Indication of

AM/PM time at

12 hour clock

Symbol for Timer programming

Symbol for

setting of clock

24 hour clock-ring

which shows

actual time and

timer programme

View of symbols in the display

Symbol for degrees

Symbol for

temperature

below set-point
